62-710 Order= 262 B 710

Montgomery Ward & Co. (Wards, Airline); Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1938–1940
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 48207
    • Brand: Airline or Air-Line

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 115 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
  • Power out
  • 1.5 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 62-710 Order= 262 B 710 - Montgomery Ward & Co. Wards,
  • Dimensions (WHD)
  • 32.5 x 33.25 x 16 inch / 826 x 845 x 406 mm
  • Notes

  • BC (528-1730 kHz) band with 6 station pushbuttons and SW (5.75-18.3 MHz) band. Tuning eye. 6 or 8 or 10 inch speaker.

    Same Model with 9 Tubes: Model 62-910. With 11 Tubes: Model 93WG-1110.

  • Price in first year of sale
  • 56.95 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 10 = 1939 and before
  • Mentioned in
  • Rider's 10-15, 10-43, 10-46, 10-49
