Temp - Темп 6

Temp - Темп 6; Moscow Radio (ID = 935498) Television
Temp - Темп 6; Moscow Radio (ID = 935497) Television Temp - Темп 6; Moscow Radio (ID = 2570713) Television
Temp - Темп 6; Moscow Radio (ID = 2570714) Television Temp - Темп 6; Moscow Radio (ID = 2570716) Television
Temp - Темп 6; Moscow Radio (ID = 2570717) Television Temp - Темп 6; Moscow Radio (ID = 2570718) Television
Temp - Темп 6; Moscow Radio (ID = 2570737) Television
Use red slider bar for more.
Temp - Темп 6; Moscow Radio (ID = 935497) Television
Moscow Radio: Temp - Темп 6 [Television] ID = 935497 933x763
Select picture or schematic to display from thumbnails on the right and click for download.
For model Temp - Темп 6, Moscow Radio engineering Works:
G.P. Samojlov, 1965

Country:  Soviet Union
Manufacturer / Brand:  Moscow Radio engineering Works
Year: 1960 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 18: 6Ж1П 6Ж1П 6Ф3П 6Ж1П 6Ж1П 6Ж1П 6Ж5П 6П15П 6Ф1П 6Н2П 6Ф3П 6Н1П 6П31С 6Д14П 3Ц18П 6Н14П 6Ф1П 43lk9b
Main principle Superheterodyne (common)
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Temp - Темп 6 - Moscow Radio engineering Works
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes 19 diodes.
Picture size: 305x380 mm
Picture IF: 38 MHz
Sound IF I: 31.5 MHz
Sound IF II: 6.5 MHz
The TV has an audio output plug.
Literature/Schematics (1) G.P. Samojlov, 1965
