Rubin {Рубин} 401BG

Rubin {Рубин} 401BG; Moscow Radio-TV (ID = 137248) Television Rubin {Рубин} 401BG; Moscow Radio-TV (ID = 1573434) Television
Use red slider bar for more.
Rubin {Рубин} 401BG; Moscow Radio-TV (ID = 137248) Television
Moscow Radio-TV: Rubin {Рубин} 401BG [Television] ID = 137248 333x258
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rubin {Рубин} 401BG, Moscow Radio-TV Works (MRTZ):
Courtesy of V.Charcenko ..rw6ase.narod.ru

Country:  Soviet Union
Manufacturer / Brand:  Moscow Radio-TV Works (MRTZ)
Year: 1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: 59ЛК3Ц
Semiconductors (the count is only for transistors) 15:
Main principle Super-Heterodyne (Super in general)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Rubin {Рубин} 401BG - Moscow Radio-TV Works MRTZ
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 746 x 518 x 495 mm / 29.4 x 20.4 x 19.5 inch
Notes Secam Standard Soviet Color TV; Usable Picture Size: 475 × 370 mm; 350 Watts Power consumption; 54 Diodes. VHF Kanal 2..12, UHF-Kanal 21...39, SECAM CCIR, Import in die DDR
Net weight (2.2 lb = 1 kg) 65 kg / 143 lb 2.7 oz (143.172 lb)
Price in first year of sale 3'400.00 DM
Literature/Schematics (1) Funkamateur Heft 2/1970 Seiten62-63

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Moscow Radio-TV Works (MRTZ)
Here you find 29 models, 25 with images and 18 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
