12BP71AY-2 Ch= WTS-454
Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1966
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 239194
Picture from Motorola Datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Valves / Tubes
- 3HA5 or 3HM5 6KZ8 4BZ6 5JK6 10DX8 or LCL84 6LN8 or LCF80 17BF11 6LN8 or LCF80 10CW5 33GY7 1X2 12BGP4 or 12BKP4
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 3 inch = 7.6 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 12BP71AY-2 Ch= WTS-454 - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Tablemodel, low profile (big size).
- Notes
-
The Motorola 12BP71AY-2 is a 12" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis WTS-454, VHF tuner CMTT-393Y, UHF tuner TT-622 or KTT-622 and picture tube 12BGP4 or 12BKP4. Table model with plastic cabinet, with white cabinet front and yellow cabinet back.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (2)
- - - Manufacturers Literature (Motorola Datasheet 68P65135A16 Dated 2-65)
- Literature/Schematics (3)
- - - Manufacturers Literature (Motorola Datasheet 68P65135A18 Dated 3-66)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
