• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1953 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 333592

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• 6CB6 6U8 6CB6 6CB6 6CB6 6AH6 6AU6 6AL5 6SN7GT 25L6GT 12SN7GT 12BH7 6SN7GT 25BQ6GT 12AX4GT 1B3GT 17LP4

• Main principle
• Superhet with RF-stage; Export model

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 17T13 Ch= TS-410A - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel, with any shape - general.

• Notes

• Motorola model 17T13E is a 17” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis TS-410A, VHF tuner 1U720225 and picture tube 17LP4.

• Mentioned in
• -- Original prospect or advert (Dal settimanale di Mondadori "Epoca", dicembre 1954.)

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 194, folder 9, dated 2-53)

• Author
• Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
