21C2B Ch= TS502

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1954 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 205856

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• 6BQ7A or 6BZ7 6U8 6CB6 6CB6 6CB6 12BY7 6AU6 6AU6 6AL5 6SN7GT 6W6GT 6SN7GT 12BH7 6SN7GT 6BQ6GT 6AX4GT 1B3GT 21FP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 21C2B Ch= TS502 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel, with any shape - general.

• Notes

• Motorola model 21C2B is a 21” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis TS-502, VHF tuner TT53 and picture tube 21FP4A. Table model, limed oak with de-tachable console-height legs.

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (3)
• Photofact Folder, Howard W. SAMS (Set 237, folder 8, dated 4-54)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
