• Year
  • 1956 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 272433

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 19
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 21K48B Ch= TS-534 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • MOTOROLA Model 21K48B is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13 . Equipped with VHF-Tuner TT-79, chassis TS-534 and Picture tube 21ALP4A.

  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
