Y21K123B, M, Y21T64B, M, W Ch= TS-556Y

Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

  • Year
  • 1959
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 155473

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Valves / Tubes
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Y21K123B, M, Y21T64B, M, W Ch= TS-556Y - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • 21" b/w Television Receiver, Picture tube: 21CBP4A, Some models are equipped with continuous UHF tuner, tube quantity UHF: 17.
    Tuning Range: TV - Channels 2 thru 13 VHF, 14 thru 84 UHF.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
