• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1950

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 49199

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6BA6 6BE6 6BA6 6AT6 6AQ5 6X4

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Power out
• 3.5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: 700 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 7 x 4.5 x 5.2 inch / 178 x 114 x 132 mm

• Notes
• Vibrator for +B , Push-button tuning.
  Receiver consists of a tuning unit and of a audio&power unit.

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 21, Copyright 1950

• Literature/Schematics (1)
• Beitman Radio Diagrams, Vol. 10, 1950
