79XM21 Ch= HS-168

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075388) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075389) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075390) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075391) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075392) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075393) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075394) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1075395) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 109681) Radio

79XM21 Ch= HS-168; Motorola Inc. ex (ID = 270819) Radio
79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1779787) Radio 79XM21 Ch= HS-168; Motorola Inc. ex (ID = 50885) Radio
79XM21 Ch= HS-168; Motorola Inc. ex (ID = 199027) Radio 79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1339417) Radio
79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1339419) Radio 79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1455024) Radio
79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1462461) Radio 79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1693210) Radio
Use red slider bar for more.
79XM21 Ch= HS-168; Motorola Inc. ex (ID = 1779787) Radio
Motorola Inc. ex: 79XM21 Ch= HS-168 [Radio] ID = 1779787 1136x852
Select picture or schematic to display from thumbnails on the right and click for download.
For model 79XM21 Ch= HS-168, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Year: 1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12BA6 12BE6 12BA6 12BA6 19T8 50C5
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: 79XM21 Ch= HS-168 - Motorola Inc. ex Galvin Mfg.Co
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 13.25 x 8 x 8 inch / 337 x 203 x 203 mm
Notes Selenium Rectifier
Color=Green
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 20 covering 1950
Mentioned in Table Top Radios Vol. 1 Stein 98
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 10, 1950
