For model A19T2-3 Ch= WTS-435, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL):
Picture from Motorola Datasheet
| Main principle |
Superhet with RF-stage
|
| Wave bands |
VHF incl. FM and/or UHF (see notes for details) |
| Details |
|
| Power type and voltage |
Alternating Current supply (AC) / 60 cycles, 120 Volt |
| Loudspeaker |
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out |
|
| from Radiomuseum.org |
Model: A19T2-3 Ch= WTS-435 - Motorola Inc. ex Galvin Mfg.Co |
| Material |
Wooden case |
| Shape |
Tablemodel, low profile (big size). |
| Notes |
The Motorola A19T2-3 is a 19" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis WTS-435, VHF tuner 2ATT-133 and picture tube 19AFP4. Uses Elliptical 3" x 5" PM speaker. Table model, walnut cabinet. Has factory installed remote control tuning system that uses remote control TR-9. Has Qty(2) Selenium Rectifiers used for the phase detector, Qty(2) diodes used for power supply rectification and Qty(1) germanium diode video detector. |
| Source of data |
- - Manufacturers Literature |
| Literature/Schematics (1) |
- - Manufacturers Literature (Motorola Datasheet 68P65110A07) |
| Literature/Schematics (2) |
Photofact Folder, Howard W. SAMS (Set 533 Folder 1 1961) |
Model page created by John Kusching. See "Data change" for further contributors.
