For model A19T2-4 Ch= WTS-435, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL):
Picture from Motorola Datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Year: 1960 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: 4ES8 5EU8 3BZ6 3BZ6 8GN8 3BU8 or 3GS8 3BU8 3DT6 8BQ5 5EA8 or 5GH8 12DQ6B 12AF3 3A3 7EY6 19AFP4
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: A19T2-4 Ch= WTS-435 - Motorola Inc. ex Galvin Mfg.Co
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes

The Motorola A19T2-4 is a 19" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis WTS-435, VHF tuner 2ATT-133 and picture tube 19AFP4.  Uses Elliptical 3" x 5" PM speaker.  Table model, cherrywood cabinet. Has factory installed remote control tuning system that uses remote control TR-9. Has Qty(2) Selenium Rectifiers used for the phase detector, Qty(2) diodes used for power supply rectification and Qty(1) germanium diode video detector.

Source of data - - Manufacturers Literature
Literature/Schematics (1) - - Manufacturers Literature (Motorola Datasheet 68P65110A07)
Literature/Schematics (2) Photofact Folder, Howard W. SAMS (Set 533 Folder 1 1961)

Model page created by John Kusching. See "Data change" for further contributors.
