For model A21C5M Ch= TTS-539, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL):
Data taken from Motorola datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Year: 1957 Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: 6BC8 6U8 6BZ6 6BZ6 6CB6 12BY7A 6AU6 6U8 6AU6 6AL5 6AQ5 6SN7GTB 6SN7GTB 6SN7GTB 6DQ6 6AU4 1B3 6AQ5 5U4GB 5U4GB 21ATP4A
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: A21C5M Ch= TTS-539 - Motorola Inc. ex Galvin Mfg.Co
Material Wooden case
Shape Console with any shape - in general
Notes 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Consolette model, mahogany, masonite. Equipped with motor drive unit for channel selection, controlled by front panel push-buttons or by remote control.
Source of data - - Manufacturers Literature

Model page created by John Kusching. See "Data change" for further contributors.
