A21K63CW Ch= TTS-539; Motorola Inc. ex (ID = 1121805) Television
Motorola Inc. ex: A21K63CW Ch= TTS-539 [Television] ID = 1121805 743x840
Select picture or schematic to display from thumbnails on the right and click for download.
For model A21K63CW Ch= TTS-539, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL):
Picture from Motorola datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Year: 1957 Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: 6BC8 6U8 6BZ6 6BZ6 6CB6 12BY7A 6AU6 6U8 6AU6 6AL5 6AQ5 6SN7GTB 6SN7GTB 6SN7GTB 6DQ6 6AU4 1B3 6AQ5 5U4GB 5U4GB 21ATP4A
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: A21K63CW Ch= TTS-539 - Motorola Inc. ex Galvin Mfg.Co
Material Wooden case
Shape Console with any shape - in general
Notes 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Console model, cherry, wood. Equipped with motor drive unit for channel selection, controlled by front panel push-buttons or by remote control.
Source of data - - Manufacturers Literature
Mentioned in Photofact Folder, Howard W. SAMS (Set 384 Folder 5 Production Changes Bulletin 197 dated 1-58)

Model page created by John Kusching. See "Data change" for further contributors.
