A9P Ch= HS-809

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148571) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148572) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148573) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148574) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148575) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148576) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148577) Radio

A9P Ch= HS-809; Motorola Inc. ex (ID = 1148578) Radio
A9P Ch= HS-809; Motorola Inc. ex (ID = 1148570) Radio
Use red slider bar for more.
A9P Ch= HS-809; Motorola Inc. ex (ID = 1148570) Radio
Motorola Inc. ex: A9P Ch= HS-809 [Radio] ID = 1148570 646x527
Select picture or schematic to display from thumbnails on the right and click for download.
For model A9P Ch= HS-809, Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL):
Picture from Motorola datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
Year: 1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: A9P Ch= HS-809 - Motorola Inc. ex Galvin Mfg.Co
Material Plastics (no bakelite or catalin)
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Notes The Motorola Model A9P is an AC/DC operated 5 Tube AM Receiver. Color = Pink. BC Band Tuning Range: 535 to 1620KHz. This model is part of the A9, A10, C7, C8, C9 and C9-1 series of radios that share a common schematic (C7, C8, C9, C9-1 series also have an electric clock).
Source of data - - Manufacturers Literature

Model page created by John Kusching. See "Data change" for further contributors.
