• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216083

• Number of Transistors
• 6

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: All Transistor X54B Ch= HS-6123 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 2.25 x 3.5 x 1 inch / 57 x 89 x 25 mm

• Notes

• The following models are identical except for cabinet color.

  Model Number	Cabinet Color
  X54B	Blue
  X54E	Black



• Mentioned in
• Collector's Guide To TrR1 Bunis trans.94 (1996, page 176)

• Literature/Schematics (1)
• Beitman Radio Diagrams, Vol. 24, 1964 (page 91)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
