B12W Ch= HS-4134

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 92793

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 17EW8 or HCC85 12BA6 12BA6 12AU6 12BE6 12AV6 35C5

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• AC/DC-set / 110 to 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: B12W Ch= HS-4134 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Notes

• The Motorola B12W is an AC/DC operated 7 tube AM/FM receiver. AM Tuning Range: 535 to 1620 kHz. FM Tuning range: 88 to 108MHz.  Has Qty(1) PM 5" speaker. Has built-in ferrite antenna for AM and a 36" wire for the FM antenna. Uses silicon diode for rectifier in power supply.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 25, 1965

• Mentioned in
• Photofact Folder, Howard W. SAMS (Set 733, Folder 9)

• Literature/Schematics (1)
• - - Manufacturers Literature (Motorola Datasheet 68P60084A25 Dated 4-64)

• Literature/Schematics (2)
• Beitman Radio Diagrams, Vol. 25, 1965 (Pages 66, 67, 68)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
