• Year
  • 1967
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 238706

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 19
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: CL882DW Ch= C23TS-921 - Motorola Inc. ex Galvin Mfg.Co
  • Shape
  • Console with any shape - in general
  • Notes
  • The Motorola CL882DW is a 25" color TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis C23TS-921, VHF tuner LOPTT-399, UHF tuner HTT-624 or HTT-627 and picture tube 25AP22 or 25SP22. Console model with Walnut wooden cabinet.

  • Source of data
  • - - Manufacturers Literature
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Motorola Datasheet 68P65155A01 Dated 9-67)
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
