Ch= HS-253

Ch= HS-253; Motorola Inc.; (ID = 1077645) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077646) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077647) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077648) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077649) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077650) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077651) Radio

Ch= HS-253; Motorola Inc.; (ID = 1077652) Radio

Ch= HS-253; Motorola Inc.; (ID = 519560) Radio

Ch= HS-253; Motorola Inc.; (ID = 519561) Radio
Use red slider bar for more.
Ch= HS-253; Motorola Inc.; (ID = 1077645) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc.; Schaumburg (IL)
alternative name

Galvin Mfg. Co. ; Chicago
Year: 1953 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6BA6 6BA7 6BA6 6BA6 6AL5 6AV6 6K6GT 5Y3GT
Main principle Superhet with RF-stage; ZF/IF 455/10700 kHz
Tuned circuits 7 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Ch= HS-253 - Motorola Inc.; Schaumburg IL
Notes Built in loop antenna for BC. This chassis is used with model 17F1 series , 17F2 series , 17F3 series , 17F4 series ( tv-sets)
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 21, Copyright 1950
Literature/Schematics (1) Riders 21-32 to 21-38
