• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1967

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 215623

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)     11 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TC11CN Ch= HS-68212 - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Notes
• The Motorola model TC11CN is a 10 transistor AM/FM Clock radio. AM Tuning Range: 535 to 1620 kHz. FM Tuning Range: 88 to 108 MHz. Has Qty(1) PM Elliptical 4" x 6" speaker. Cabinet color is Beige. Motorola models TC11CH, TC11CL, TC13CS and TC13CW use the same chassis and schematic.

• Literature/Schematics (1)
• - - Manufacturers Literature (Motorola Datasheet 68P63011A22)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
