VM19RC

• Country
• United States of America (USA)

• Manufacturer / Brand
• Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)

• Year
• 1959 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 210285

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: VM19RC - Motorola Inc. ex Galvin Mfg.Co

• Shape
• Chassis only or for «building in»

• Notes
• Motorola model VM19RC is a four speed automatic record changer, part number 59K642270. This record changer is designed to play 7", 10" and 12" records at 78, 33-1/3, 45 and 16-2/3 RPM. The 16-2/3 RPM records should be played manually. Ten 12", twelve 10" or fourteen 7" records (using 45 RPM adapter spindle) can be played automatically. This record changer operates from 60 cycle AC only.

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
