Y14P11-2 Ch= TS-425
Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Motorola Inc. (ex Galvin Mfg.Co. Chicago); Schaumburg (IL)
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 310724
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Y14P11-2 Ch= TS-425 - Motorola Inc. ex Galvin Mfg.Co
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Motorola model Y14P11-2 is a 14" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis TS-425, VHF tuner TT-93 and picture tube 14WP4.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 362 Folder 17-S dated 6-57)
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 369 Folder 14 dated 9-57)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
