Discovery (Direction finder) GND-517

Discovery GND-517; Mullard Wireless, (ID = 1931430) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931431) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931432) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931433) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931434) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931435) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931436) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931437) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931438) Commercial Re

Discovery GND-517; Mullard Wireless, (ID = 1931439) Commercial Re
Discovery GND-517; Mullard Wireless, (ID = 1931424) Commercial Re Discovery GND-517; Mullard Wireless, (ID = 1931425) Commercial Re
Discovery GND-517; Mullard Wireless, (ID = 1931426) Commercial Re Discovery GND-517; Mullard Wireless, (ID = 1931428) Commercial Re
Discovery GND-517; Mullard Wireless, (ID = 1931429) Commercial Re
Use red slider bar for more.
Discovery GND-517; Mullard Wireless, (ID = 1931424) Commercial Re
Mullard Wireless,: Discovery GND-517 [Commercial Re] ID = 1931424 1200x1044
Select picture or schematic to display from thumbnails on the right and click for download.
For model Discovery (Direction finder) GND-517, Mullard Wireless, London (see also Mullard Radio Valve):
Picture from Mullard manual

Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1954 ?? Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 7: UAF42 UCH42 UAF42 UAF42 EM34 UAF42 UAF42
Main principle Superheterodyne (common); ZF/IF 110 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Line / Storage batteries (perhaps also batteries) / AC: 115; 230 / DC: 24; 110; 220 Volt
Loudspeaker - Is a Headphone or Earphone
Power out
from Radiomuseum.org Model: Discovery GND-517 - Mullard Wireless, London see
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 16.5 x 12 x 11 inch / 419 x 305 x 279 mm
Notes

Direction finding equipment designed for the reception of types A1, A2 and A3 (c.w., m.c.w, and r.t.) signals in the Maritime Radio Beacon bands, covering a frequency range of 255kc/s to 525 kc/s and 1.6 Mc/s to 2.9 Mc/s.

Net weight (2.2 lb = 1 kg) 40 lb 0 oz (40 lb) / 18.160 kg
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
