Projection TV EHT Unit

Projection TV EHT Unit; Mullard Wireless, (ID = 1028465) Misc

Projection TV EHT Unit; Mullard Wireless, (ID = 1028466) Misc
Use red slider bar for more.
Projection TV EHT Unit; Mullard Wireless, (ID = 1028465) Misc
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1951 Category: Miscellaneous (Other, Various) - see notes
Valves / Tubes 5: EBC33 or ECL80 EL38 or PL820 EY51 EY51 EY51
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Projection TV EHT Unit - Mullard Wireless, London see
Material Various materials
Shape Chassis only or for «building in»
Notes The EHT unit for use with the Mullard Projection TV unit.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1119/T46)

Model page created by Howard Craven. See "Data change" for further contributors.
