MKB-2043

MKB-2043; Mullard Wireless, (ID = 1341916) Radio MKB-2043; Mullard Wireless, (ID = 1317215) Radio
MKB-2043; Mullard Wireless, (ID = 1341931) Radio MKB-2043; Mullard Wireless, (ID = 1341915) Radio
MKB-2043; Mullard Wireless, (ID = 1341919) Radio MKB-2043; Mullard Wireless, (ID = 1341934) Radio
MKB-2043; Mullard Wireless, (ID = 1318048) Radio MKB-2043; Mullard Wireless, (ID = 1341914) Radio
MKB-2043; Mullard Wireless, (ID = 1341917) Radio MKB-2043; Mullard Wireless, (ID = 1341926) Radio
Use red slider bar for more.
MKB-2043; Mullard Wireless, (ID = 1341916) Radio
Mullard Wireless,: MKB-2043 [Radio] ID = 1341916 930x705
Select picture or schematic to display from thumbnails on the right and click for download.
For model MKB-2043, Mullard Wireless, London (see also Mullard Radio Valve)

Country:  Great Britain (UK)
Manufacturer / Brand:  Mullard Wireless, London (see also Mullard Radio Valve)
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK96 DF96 DAF96 DL96
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Storage and/or dry batteries / 1,5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: MKB-2043 - Mullard Wireless, London see
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 335 x 170 x 142 mm / 13.2 x 6.7 x 5.6 inch
Notes

SW-OC 1: 13...38 m
SW-OC 2: 36...92 m.

Probably a Philips Export model using Mullard branding. Mullard Radio production (almost entirely Philips models) appears to have ended in early 1950s. Not for Domestic UK market.

Model page created by Daniel Rosha. See "Data change" for further contributors.



All listed radios etc. from Mullard Wireless, London (see also Mullard Radio Valve)
Here you find 139 models, 107 with images and 57 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
