A104

A104; Murphy Radio Ltd.; (ID = 275246) Radio
A104; Murphy Radio Ltd.; (ID = 161111) Radio A104; Murphy Radio Ltd.; (ID = 173546) Radio
A104; Murphy Radio Ltd.; (ID = 191183) Radio A104; Murphy Radio Ltd.; (ID = 191184) Radio
A104; Murphy Radio Ltd.; (ID = 191185) Radio A104; Murphy Radio Ltd.; (ID = 191186) Radio
A104; Murphy Radio Ltd.; (ID = 191187) Radio A104; Murphy Radio Ltd.; (ID = 191188) Radio
A104; Murphy Radio Ltd.; (ID = 191189) Radio A104; Murphy Radio Ltd.; (ID = 1102902) Radio
Use red slider bar for more.
A104; Murphy Radio Ltd.; (ID = 161111) Radio
Murphy Radio Ltd.;: A104 [Radio] ID = 161111 923x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model A104, Murphy Radio Ltd.; Welwyn Garden City

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TH41 VP41 HL41DD UU6 Pen45
Main principle Superheterodyne (common); ZF/IF 465 kHz; 1 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110/240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16.5 cm = 6.5 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: A104 - Murphy Radio Ltd.; Welwyn
Material Wooden case
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 23.75 x 18 x 5.5 inch / 603 x 457 x 140 mm
Notes Separate SW dial using optical projection with magnifying lens.
First shown at the "Britain Can Make It" Exhibition. First of the baffle board series. Can alternatively be hung on the wall.
Net weight (2.2 lb = 1 kg) 12.6 kg / 27 lb 12.1 oz (27.753 lb)
Source of data Radio! Radio!

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from Murphy Radio Ltd.; Welwyn Garden City
Here you find 326 models, 229 with images and 206 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Murphy Radio Ltd.;: A104
Threads: 1 | Posts: 1
Hits: 1839     Replies: 0
murphy: A104 (A 104); Was ist Original
Harald Pohlmann
15.Mar.06
  1 Mein Gehäuse ist in einem deckenden Weinrot lackiert, so dass die Holzmaserung nicht sichtbar ist. Es ist sehr sauber gearbeitet, so dass ich nicht beurteilen kann, ob es original oder restauriert ist. Auf der Rückseite sieht man die Übergänge der aufgespritzten Farbe zum Holz.
Von den beiden Elkos ist einer ausgetauscht worden. Sie sitzen jedoch beide verschieden hoch in den Halteschellen. Wie war die ursprüngliche Anordnung?

Murphy Radio Ltd.;: A104
