A122M

A122M; Murphy Radio Ltd.; (ID = 2277331) Radio

A122M; Murphy Radio Ltd.; (ID = 2277332) Radio

A122M; Murphy Radio Ltd.; (ID = 2277333) Radio

A122M; Murphy Radio Ltd.; (ID = 2277334) Radio

A122M; Murphy Radio Ltd.; (ID = 234308) Radio
A122M; Murphy Radio Ltd.; (ID = 231614) Radio A122M; Murphy Radio Ltd.; (ID = 231615) Radio
A122M; Murphy Radio Ltd.; (ID = 231616) Radio A122M; Murphy Radio Ltd.; (ID = 231617) Radio
Use red slider bar for more.
A122M; Murphy Radio Ltd.; (ID = 231614) Radio
Murphy Radio Ltd.;: A122M [Radio] ID = 231614 710x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model A122M, Murphy Radio Ltd.; Welwyn Garden City

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: TH41 VP41 HL41DD Pen45 UU6
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: A122M - Murphy Radio Ltd.; Welwyn
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 24.3 x 18 x 8.75 inch / 617 x 457 x 222 mm
Notes Spezielle Form: Tiefe unten 200 mm. Tiefe oben: nur 50 mm. Released in January 1949 price £26 17s 9d
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Price in first year of sale 27.00 GBP
Source of data - - Data from my own collection

Model page created by Jozef Brughmans †. See "Data change" for further contributors.
