- Country
- Great Britain (UK)
- Manufacturer / Brand
- Murphy Radio Ltd.; Welwyn Garden City
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 96844
DE MI COLECCION DE ESQUEMAS
nella mia completa disponibilita'
nella mia disponibilita'
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: A170 - Murphy Radio Ltd.; Welwyn
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 22 x 17 x 8 inch / 559 x 432 x 203 mm
- Net weight (2.2 lb = 1 kg)
- 25 lb 0 oz (25 lb) / 11.350 kg
- Price in first year of sale
- 355.00 Hfl
- Source of data
- Technisch- Commercieel - Radio Vademecum Staleman
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by John Koster. See "Data change" for further contributors.
