A186 Welwyn

A186; Murphy Radio Ltd.; (ID = 1050466) Radio

A186; Murphy Radio Ltd.; (ID = 1050467) Radio

A186; Murphy Radio Ltd.; (ID = 1050468) Radio

A186; Murphy Radio Ltd.; (ID = 1050469) Radio
A186; Murphy Radio Ltd.; (ID = 1946392) Radio A186; Murphy Radio Ltd.; (ID = 1946395) Radio
A186; Murphy Radio Ltd.; (ID = 1946397) Radio A186; Murphy Radio Ltd.; (ID = 1946398) Radio
Use red slider bar for more.
A186; Murphy Radio Ltd.; (ID = 1946392) Radio
Murphy Radio Ltd.;: A186 [Radio] ID = 1946392 933x770
Select picture or schematic to display from thumbnails on the right and click for download.
For model A186 Welwyn, Murphy Radio Ltd.; Welwyn Garden City:
A 1951 Murphy A186 table radio, Ebay item no 262247424953 seller nt4474

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6C9_UK 6F15 or 6F16 6LD20 6P25 6M1_Mazda-UK or EM34 UU9 or EZ40
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: A186 [Welwyn] - Murphy Radio Ltd.; Welwyn
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes IF set to 465 kHz in early sets.
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1154)

Model page created by Peter Hoddow. See "Data change" for further contributors.



All listed radios etc. from Murphy Radio Ltd.; Welwyn Garden City
Here you find 326 models, 229 with images and 206 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
