A252

A252; Murphy Radio Ltd.; (ID = 352164) Radio

A252; Murphy Radio Ltd.; (ID = 562921) Radio

A252; Murphy Radio Ltd.; (ID = 562923) Radio
A252; Murphy Radio Ltd.; (ID = 451186) Radio A252; Murphy Radio Ltd.; (ID = 451187) Radio
A252; Murphy Radio Ltd.; (ID = 451188) Radio A252; Murphy Radio Ltd.; (ID = 767463) Radio
Use red slider bar for more.
A252; Murphy Radio Ltd.; (ID = 451186) Radio
Murphy Radio Ltd.;: A252 [Radio] ID = 451186 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model A252, Murphy Radio Ltd.; Welwyn Garden City

Country:  Great Britain (UK)
Manufacturer / Brand:  Murphy Radio Ltd.; Welwyn Garden City
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6F12 EC92 6C9_UK 6F18 EM81 6LD12 6P1 UU9
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: A252 - Murphy Radio Ltd.; Welwyn
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 21 x 17 x 8.5 inch / 533 x 432 x 216 mm
Mentioned in -- Original-techn. papers.

Model page created by Peter Hoddow. See "Data change" for further contributors.



All listed radios etc. from Murphy Radio Ltd.; Welwyn Garden City
Here you find 326 models, 229 with images and 206 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
