- Country
- Great Britain (UK)
- Manufacturer / Brand
- Murphy Radio Ltd.; Welwyn Garden City
- Year
- 1945 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 120155
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Landmuseum Binsfeld, Luxemburg
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 105-115; 200-210; 220-230; 240-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: A98 - Murphy Radio Ltd.; Welwyn
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 410 x 430 x 240 mm / 16.1 x 16.9 x 9.4 inch
- Notes
- Similar to the export model SA98.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by Jozef Brughmans †. See "Data change" for further contributors.
