682ZX

682ZX; Nakamichi Co.; Tokyo (ID = 439464) R-Player
Use red slider bar for more.
682ZX; Nakamichi Co.; Tokyo (ID = 439464) R-Player
Nakamichi Co.; Tokyo: 682ZX [R-Player] ID = 439464 391x169
Select picture or schematic to display from thumbnails on the right and click for download.
For model 682ZX, Nakamichi Co.; Tokyo:
ebay: piscosourman #200207810360

Country:  Japan
Manufacturer / Brand:  Nakamichi Co.; Tokyo
Year: 1981 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 59:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 682ZX - Nakamichi Co.; Tokyo
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 482 x 143 x 340 mm / 19 x 5.6 x 13.4 inch
Notes Stereo-Kassetten-Recorder, 3 Köpfe, Hinterbandkontrolle, 4,75 cm/sek, 5 Motoren, Frequenzgang 20-22000 Hz, Testtongenerator, elektronische Laufwerksteuerung, Fernbedienung RM 200 drahtgebunden.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 2'198.00 DM
Source of data -- Original-techn. papers.
Mentioned in - - Data from my own collection

Model page created by Manfred Schwen. See "Data change" for further contributors.



All listed radios etc. from Nakamichi Co.; Tokyo
Here you find 131 models, 105 with images and 13 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
