Amplifier 1

Nakamichi Co.; Tokyo

  • Year
  • 1990
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 156660

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Radio Control (+Remote Wire etc)
  • Power type and voltage
  • Alternating Current supply (AC) / 100 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 160 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Amplifier 1 - Nakamichi Co.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 125 x 360 mm / 16.9 x 4.9 x 14.2 inch
  • Notes
  • Integrated Stereo Amplifier with 80 watts RMS per channel into 8 ohms.
    Wireless Remote Control.
    For Japanese Market (100V mains).
  • Net weight (2.2 lb = 1 kg)
  • 15 kg / 33 lb 0.6 oz (33.04 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
