BX-1; Nakamichi Co.; Tokyo (ID = 2450136) R-Player
Nakamichi Co.; Tokyo: BX-1 [R-Player] ID = 2450136 1400x778
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX-1, Nakamichi Co.; Tokyo

Country:  Japan
Manufacturer / Brand:  Nakamichi Co.; Tokyo
Year: 1982–1984 Category: Sound/Video Recorder and/or Player
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: BX-1 - Nakamichi Co.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 110 x 250 mm / 16.9 x 4.3 x 9.8 inch
Notes

Frontloading 2 Head Stereo Cassette Deck with Dolby B, MPX Filter and Metal Tape Capability.
3-Digit Mechanical Counter, 4-Digit Digital Counter, Digital Peak-Reading Meters.
Microprocessor Control.

Type: 2-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x record/playback, 1 x erase
Motor: 1 x reel, 1 x capstan
Tape Type: type I, CrO2, Metal
Noise Reduction: B
Frequency Response: 20Hz to 20kHz  (Metal tape)
Signal to Noise Ratio: 62dB  (dolby B)
Wow and Flutter: 0.06%
Total Harmonic Distortion: 1.0%
Input: 50mV (line)
Output: 0.5V (line)

Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
