Panda Super Thin pocketable Radio B735

Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400206) Radio

Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400207) Radio
Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400202) Radio Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400203) Radio
Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400204) Radio Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400205) Radio
Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400208) Radio Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400209) Radio
Use red slider bar for more.
Panda Super Thin pocketable Radio B735; Nanjing 南京无线电厂 (ID = 2400202) Radio
Nanjing 南京无线电厂: Panda Super Thin pocketable Radio B735 [Radio] ID = 2400202 903x1398
Select picture or schematic to display from thumbnails on the right and click for download.
For model Panda Super Thin pocketable Radio B735, Nanjing 南京无线电厂 Nanjing Radio Factory, Nanjing:
Pictures from Stylianos Stylianou

Country:  People's Republic of China
Manufacturer / Brand:  Nanjing 南京无线电厂 Nanjing Radio Factory, Nanjing
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 3DG201 3DG201 3DG201 3DG201 3DG201 2CP12 3DX201
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / AA: 2 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.05 W (max.)
from Radiomuseum.org Model: Panda Super Thin pocketable Radio B735 - Nanjing 南京无线电厂 Nanjing Radio
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 71 x 118 x 20 mm / 2.8 x 4.6 x 0.8 inch
Notes

This radio has a small built in Torch (flashlight) facility.

Net weight (2.2 lb = 1 kg) 0.168 kg / 0 lb 5.9 oz (0.37 lb)
