• Country
• United States of America (USA)

• Manufacturer / Brand
• Narco, National Aeronautical Corporation; Fort Washington (PA)

• Year
• 1955

• Category
• Commercial Transmitter & Receiver (TRX not Amateur)

• Radiomuseum.org ID
• 284893

• Number of Tubes
• 10

• Valves / Tubes
• 6CB6 6AQ6 12AL5 6CB6 6BH6 6BH6 6BH6 6BH6 6BH6 5763

• Main principle
• Transceiver

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Powered by external power supply or a main unit. / 12 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Simplexer VC-12 - Narco, National Aeronautical

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 130 x 200 mm / 7.1 x 5.1 x 7.9 inch

• Notes

• For aviation use. RX: 108 - 127 MHz, Xtal controlled TX. External power unit type V12-MP2A.

• Net weight (2.2 lb = 1 kg)
• 1.4 kg / 3 lb 1.3 oz (3.084 lb)

• Author
• Model page created by Siegfried Droese. See "Data change" for further contributors.
