Neckermann-Versand: K91092 Art.Nr. 820Y32 [Radio] ID = 2486358 1400x1004

Select picture or schematic to display from thumbnails on the right and click for download.

For model K91092 Art.Nr. 820Y32 Kunststoffgitter, Neckermann-Versand KG; Frankfurt a.M.:
Seriennummer: 754179, Skalenradabdeckung fehlt

Country:

Germany

Manufacturer / Brand:

Neckermann-Versand KG; Frankfurt a.M.

Brand

Twen Tone

Year: 1961/1962

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

9: OC615 OC615 OC614 AF105 AF105 OC604 OC604 OC74 OC74 OA160 OA160 OA160 OA172 OA172

Main principle	to an article Superheterodyne (common); ZF/IF 460/10700 kHz; 3 AF stage(s)
Tuned circuits	7 AM circuit(s) 11 FM circuit(s)
Wave bands	Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage	Dry Batteries / 2 x 4,5 Volt
Loudspeaker	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org	Model: K91092 Art.Nr. 820Y32 [Kunststoffgitter] - Neckermann-Versand KG;
Material	Leather / canvas / plastic - over other material
Shape	Portable set > 8 inch (also usable without mains)
Dimensions (WHD)	260 x 175 x 85 mm / 10.2 x 6.9 x 3.3 inch
Notes	UKW-Bereich bis 100 MHz Paralleltyp zum Südfunk K91092 Siehe auch Neckermann K91092 schwarz mit Metallgitter Angeboten mit Bestellnummer 820Y32 im Katalog160 vom 1.3.61 und Katalog 161 vom 1.9.61 Hergestellt bei Südfunk-Apparatebau Stuttgart für Neckermann Versand KG.
Net weight (2.2 lb = 1 kg)	1.7 kg / 3 lb 11.9 oz (3.744 lb)
Price in first year of sale	195.00 DM
Mentioned in	Neckermann-Katalog (Nr. 160 vom 1.3.1961 und Nr. 161 vom 1.9.1961)

Model page created by Uwe Müller. See "Data change" for further contributors.

All listed radios etc. from Neckermann-Versand KG; Frankfurt a.M.
Here you find 536 models, 480 with images and 161 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Wolfgang Gebert (D)

Collection of Thomas Wern (D)

Collection of Uwe Müller (D)

Forum contributions about this model

Neckermann-Versand: K91092 Art.Nr. 820Y32

Threads: 1 | Posts: 2

Hits: 1212 Replies: 1 neckermann: K91092;
Thomas Wern 14.Jan.15	1 neckermann: K91092; Hallo, beim Modell K91092 ist ein rotes Radio abgebildet.Es handelt sich bei diesem aber um das Modell K9892, erkennbar an der Skalenscheibe.Bitte um Korrektur! Gruss Wern
Bernhard Nagel 15.Jan.15	2 Bild verschoben Danke für den Hinweis! Das Bild zeigt in der Tat einen Neckermann UKW/MW Koffer K9892, das Bild wurde entsprechend verschoben. K91092 hat dagegen 3 Wellenbereiche UKW, MW und LW.
