For model Golf 506 International RP506 55194060, Nokia Graetz GmbH; Pforzheim:
Foto de la radio Nokia Golf 506, parte delantera

Country:  Germany
Manufacturer / Brand:  Nokia Graetz GmbH; Pforzheim
Year: 1988 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / C: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 10 cm = 3.9 inch
Power out 2.6 W (unknown quality)
from Radiomuseum.org Model: Golf 506 International RP506 55194060 - Nokia Graetz GmbH; Pforzheim
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 265 x 165 x 50 mm / 10.4 x 6.5 x 2 inch
Notes

6 Bands: FM - MW - LW - SW1 - SW2 - SW3

See also ITT Golf 506 International 55162080.

Made in Malaysia.

Model page created by Jorge Eduardo Pinto-Cubillas. See "Data change" for further contributors.
