Universal Sperrkreis, Siebkreis, Saugkreis 35a

Nora; Berlin

  • Year
  • 1929 ??
  • Category
  • Radio module post 1925 (not a part, not a key)
  • Radiomuseum.org ID
  • 261678

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • RF-Circuit or wave trap (separate, can also be an antenna with amp.)
  • Tuned circuits
  • 1 AM circuit(s)
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Universal Sperrkreis, Siebkreis, Saugkreis 35a - Nora; Berlin
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 175 x 100 x 125 mm / 6.9 x 3.9 x 4.9 inch
  • Net weight (2.2 lb = 1 kg)
  • 0.750 kg / 1 lb 10.4 oz (1.652 lb)
  • Author
  • Model page created by Norbert Konersmann. See "Data change" for further contributors.
