AM-Einschub 372

AM-Einschub 372; Nordmende, (ID = 1923905) Equipment

AM-Einschub 372; Nordmende, (ID = 1923907) Equipment

AM-Einschub 372; Nordmende, (ID = 1923908) Equipment

AM-Einschub 372; Nordmende, (ID = 1923910) Equipment
AM-Einschub 372; Nordmende, (ID = 1923914) Equipment
Use red slider bar for more.
AM-Einschub 372; Nordmende, (ID = 1923914) Equipment
Nordmende,: AM-Einschub 372 [Equipment] ID = 1923914 547x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM-Einschub 372, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1969 ?? Category: Service- or Lab Equipment
Valves / Tubes 2: ECF80 EF184
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker
Power out
from Radiomuseum.org Model: AM-Einschub 372 - Nordmende, Norddeutsche Mende-
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 140 x 150 x 250 mm / 5.5 x 5.9 x 9.8 inch
Notes

AM-Einschub Typ 372 LW. MW, KW zum
Universal-Wobbel-Meßplatz UWM346/U-2

Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Walter Ahrend. See "Data change" for further contributors.
