Ambassador Chassis L15/LL15 865.713.00; Nordmende, (ID = 291175) Television
Nordmende,: Ambassador Chassis L15/LL15 865.713.00 [Television] ID = 291175 277x266
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ambassador Chassis L15/LL15 865.713.00, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1964–1966 Category: Television Receiver (TV) or Monitor
Valves / Tubes 9: ECH84 ECH84 ECC82 PCL86 PCL85 PL500 PY88 DY86 A59-11W or A59-12W
Semiconductors (the count is only for transistors) 25:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Ambassador Chassis L15/LL15 865.713.00 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 865 x 865 x 420 mm / 34.1 x 34.1 x 16.5 inch
Notes VHF/UHF. Technische Daten wie Präsident (1964), jedoch Schrank.
Net weight (2.2 lb = 1 kg) 39.5 kg / 87 lb 0.1 oz (87.004 lb)
Price in first year of sale 1'825.00 DM
Source of data Handbuch VDRG 1964/1965
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
