Ambassador Ch= L71 / LL71 - 866.713.00; Nordmende, (ID = 996163) Television
Nordmende,: Ambassador Ch= L71 / LL71 - 866.713.00 [Television] ID = 996163 933x833
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ambassador Ch= L71 / LL71 - 866.713.00, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
Quelle: Nordmende Programm 1966

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1966/1967 Category: Television Receiver (TV) or Monitor
Valves / Tubes 7: A65-11W
Semiconductors (the count is only for transistors) 28:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Ambassador Ch= L71 / LL71 - 866.713.00 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 990 x 860 x 445 mm / 39 x 33.9 x 17.5 inch
Notes VHF/UHF. Technische Daten wie Präsident (1966), jedoch Standgerät mit 65-cm-Bildröhre.
Net weight (2.2 lb = 1 kg) 44.5 kg / 98 lb 0.3 oz (98.018 lb)
Source of data Handbuch VDRG 1966/1967
Literature/Schematics (4) -- Schematic

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
