AUTOMATIC-L recorder 4.435.A

AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 358388) R-Player

AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 358389) R-Player

AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 358391) R-Player

AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 358392) R-Player

AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 358390) R-Player
AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 1670408) R-Player AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 354565) R-Player
AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 1670407) R-Player
Use red slider bar for more.
AUTOMATIC-L recorder 4.435.A; Nordmende, (ID = 1670408) R-Player
Nordmende,: AUTOMATIC-L recorder 4.435.A [R-Player] ID = 1670408 634x476
Select picture or schematic to display from thumbnails on the right and click for download.
For model AUTOMATIC-L recorder 4.435.A, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1973/1974 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: AUTOMATIC-L recorder 4.435.A - Nordmende, Norddeutsche Mende-
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 169 x 69 x 246 mm / 6.7 x 2.7 x 9.7 inch
Notes Fernbedienungsmikrofon und Kunstleder-Tragetasche im Lieferumfang.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
External source of data Erb
Source of data Katalog RFP 1973


All listed radios etc. from Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Here you find 1715 models, 1606 with images and 1235 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
