Automatic Recorder 20.410.A ab Nr.18001

Automatic Recorder 20.410.A; Nordmende, (ID = 259319) R-Player

Automatic Recorder 20.410.A; Nordmende, (ID = 259320) R-Player

Automatic Recorder 20.410.A; Nordmende, (ID = 259324) R-Player

Automatic Recorder 20.410.A; Nordmende, (ID = 259322) R-Player
Automatic Recorder 20.410.A; Nordmende, (ID = 988905) R-Player Automatic Recorder 20.410.A; Nordmende, (ID = 259325) R-Player
Automatic Recorder 20.410.A; Nordmende, (ID = 1297465) R-Player Automatic Recorder 20.410.A; Nordmende, (ID = 1297466) R-Player
Automatic Recorder 20.410.A; Nordmende, (ID = 1829495) R-Player
Use red slider bar for more.
Automatic Recorder 20.410.A; Nordmende, (ID = 988905) R-Player
Nordmende,: Automatic Recorder 20.410.A [R-Player] ID = 988905 933x774
Select picture or schematic to display from thumbnails on the right and click for download.
For model Automatic Recorder 20.410.A ab Nr.18001, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
Quelle: Nordmende Programm 1970

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1971/1972 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6: 2SB175 2SB175 2SB172 2SB172 2SB475 2SB475
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Dry Batteries / 5 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Automatic Recorder 20.410.A [ab Nr.18001] - Nordmende, Norddeutsche Mende-
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 125 x 65 x 240 mm / 4.9 x 2.6 x 9.4 inch
Notes Netzbetrieb mit zusätzlichem Netzteil möglich. Mikrofon mit Fernbedienungsschalter und Leder-Tragetasche im Lieferumfang.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
External source of data Erb
Source of data Handbuch VDRG 1971/1972
Literature/Schematics (1) -- Original-techn. papers.
