Boheme Stereo 971.149A Ch= 769.138C; Nordmende, (ID = 303425) Radio
Nordmende,: Boheme Stereo 971.149A Ch= 769.138C [Radio] ID = 303425 439x443
Select picture or schematic to display from thumbnails on the right and click for download.
For model Boheme Stereo 971.149A Ch= 769.138C, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1970/1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 24: AF106 AF125 AF121 AF137 BFY39 BC149 BC139 AD161 AD162 AD150 BFY40 AA112 AA118 AA119 SiG0,5/50R ZD16 Si-Br-Gl
Main principle Superheterodyne (common)
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Boheme Stereo 971.149A Ch= 769.138C - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 865 x 810 x 380 mm / 34.1 x 31.9 x 15 inch
Notes Halbleiter teils mehrfach vorhanden

UKW: 87,5 - 104 MHz
KW: 5950 - 6200 kHz
MW: 515 - 1650 kHz
LW: 140 - 360 kHz

Phono-Chassis = Philips GC036.
Net weight (2.2 lb = 1 kg) 37.4 kg / 82 lb 6.1 oz (82.379 lb)
External source of data Erb
Source of data Handbuch VDRG 1970/1971
Literature/Schematics (1) -- Original-techn. papers.
