For model Bornholm 3.125A Ch= 733.122B, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
(c) eBay-Verkäufer - macheins - 26. Dez. 2011 - 160702513034

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1972/1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: BF314 BF256 BF343 BF343 BF450 BF450 BF241 TBA641 BA180 AA112 AA112 AA112 Si-Br-Gl
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Bornholm 3.125A Ch= 733.122B - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 584 x 128 x 156 mm / 23 x 5 x 6.1 inch
Notes UKW: 87,5 - 108 MHz
KW: 5950 - 6200 kHz
MW: 515 - 1650 kHz
LW: 145 - 260 kHz
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Josef Pilz. See "Data change" for further contributors.
