For model Bornholm-Stereo Ch= 6/675, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen:
Quelle: Nordmende Programm 1966

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1965/1966 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EAF801 ECC808 ELL80 EMM803 ECC81
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Bornholm-Stereo Ch= 6/675 - Nordmende, Norddeutsche Mende-
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1065 x 790 x 370 mm / 41.9 x 31.1 x 14.6 inch
Notes Dioden: 2× OA79, 11× OA81.
Stereo-Decoder eingebaut, Stereo-NF-Verstärker mit 2 Endstufen je 3 W.
Phono-Chassis = Philips AG3306.
Net weight (2.2 lb = 1 kg) 42.5 kg / 93 lb 9.8 oz (93.612 lb)
External source of data erb
Source of data Handbuch VDRG 1965/1966
Literature/Schematics (1) -- Original-techn. papers.
