Bornholm-Stereo Ch= 5/630 Teak
Use red slider bar for more.
Nordmende,: Bornholm-Stereo Ch= 5/630 [Radio] ID = 1404757 449x337
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1964/1965 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 7: ECC85 ECH81 EAF801 ECC808 EMM803 ELL80 ECC81 | ||||
|---|---|---|---|---|---|
| Semiconductors (the count is only for transistors) | 1: AF117 |
| Main principle | Superheterodyne (common); ZF/IF 460/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Long Wave, Short Wave plus FM or UHF. |
| Details | Changer (Record changer) |
| Power type and voltage | Alternating Current supply (AC) / 110/220 Volt |
| Loudspeaker | 2 Loudspeakers |
| Power out | |
| from Radiomuseum.org | Model: Bornholm-Stereo Ch= 5/630 [Teak] - Nordmende, Norddeutsche Mende- |
| Material | Wooden case |
| Shape | Console with Push Buttons. |
| Dimensions (WHD) | 1065 x 735 x 370 mm / 41.9 x 28.9 x 14.6 inch |
| Notes |
Stereo-Decoder eingebaut; |
| Net weight (2.2 lb = 1 kg) | 32.5 kg / 71 lb 9.4 oz (71.586 lb) |
| Price in first year of sale | 1'050.00 DM |
| External source of data | Erb |
| Source of data | Handbuch VDRG 1964/1965 |
| Literature/Schematics (1) | -- Original-techn. papers. |
