Elektra V13 Ch= 4/613

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1963/1964
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 25483

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110/220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 4 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Elektra V13 Ch= 4/613 - Nordmende, Norddeutsche Mende-
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 410 x 245 x 180 mm / 16.1 x 9.6 x 7.1 inch
  • Net weight (2.2 lb = 1 kg)
  • 4.9 kg / 10 lb 12.7 oz (10.793 lb)
  • Price in first year of sale
  • 275.00 DM
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Elektra is part of the collections of the following members.

 Forum

Forum contributions about this model: Nordmende,: Elektra V13 Ch= 4/613

Threads: 1 | Posts: 2

Hello. I have repaired an Elektra 4/613. It needed only a few capacitors in the audio section to be replaced, and now sounds and plays wonderfully. Only one minor problem remains. The FM stations are about 1 MHz lower than they should be at the top of the band around 106 MHz. At 90 MHz the tracking is quite acceptable. The sensitivity is very good across the entire band.

Unfortunately I do not speak German, so I can not follow the alignment procedure available on this website. I wonder if someone could tell me which adjustment would improve the tracking at the high end of the band.

Regards Tom

Tom Seeger, 05.Jul.13

Weitere Posts (2) zu diesem Thema.
