Experience E-3602

Experience E-3602; Nordmende, (ID = 1180727) Equipment Experience E-3602; Nordmende, (ID = 1180728) Equipment
Experience E-3602; Nordmende, (ID = 1180729) Equipment
Use red slider bar for more.
Experience E-3602; Nordmende, (ID = 1180727) Equipment
Nordmende,: Experience E-3602 [Equipment] ID = 1180727 933x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model Experience E-3602, Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Country:  Germany
Manufacturer / Brand:  Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
Year: 1970 ? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 2:
Main principle Radio Frequency Amplification only
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Experience E-3602 - Nordmende, Norddeutsche Mende-
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 240 x 140 x 103 mm / 9.4 x 5.5 x 4.1 inch
Notes

Der HF Generator E 3603 liefert 100 mV HF-Spannung im Bereich von 149 ... 350 MHz (Aufgeteilt in 8 Bereiche). Die HF ist mit 400 Hz modulierbar.

Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Source of data - - Data from my own collection
Mentioned in Funk-Technik (FT) (21/1970, S. 855 / Beschreibung)

Model page created by Jörg Schäfer. See "Data change" for further contributors.
